ISOTEK V5 ELEKTRA – Incl. Initium Power Cable

• Suitable for all audio or AV systems
• RFI reduction 55dB
• 6 optimised power cleaning circuits to effectively remove Common and Differential Mode mains noise
• 4 independent outlets for source components (5A)
• 2 independent high current outlets for power amps, active subwoofers, active speakers etc. (10A)
• Easy replacement fusing system
• 67’500A instantaneous protection, 32’500A continuous
• Fully star-earthed network
• 6n oxygen free copper silver-plated internal wiring with FEP dielectric
• System Link outlet for extending the outlets and maintaining a starred earth reference
• Supplied with IsoTek EVO3 Initium power cable

IsoTek V5 Elektra Power Conditioner Essentially Offers Six Power-Cleaning Systems in a Single Component, and it Includes an Initium C13 Power Cable
The superb V5 Elektra power conditioner offers legendary IsoTek performance, six power-cleaning systems in one box, and an Initium C13 Power Cable—all at an accessible price. It might sound too good to be true, but that is exactly what you get with the V5 Elektra. An extremely cost-effective upgrade, V5 Elektra features individual power-cleaning networks dedicated to each outlet. Therefore, this exquisite six-way mains power-cleaning unit is essentially six individual power-cleaning systems in one robust component. Clean power leads to highly detailed playback with more spacious soundstages, enhanced dynamics, and more immediate timing.

Additionally, IsoTek’s unique sequential and repeatable protection system ensures that your connected components remain safe. Worrying about surges and spikes will be a thing of the past when you connect your equipment to the V5 Elektra.

The V5 Elektra’s protection rating is four times the minimum requirement, raised to 67,500A instantaneous. The unit features two high-current outlets (for amplifiers) that are driven by a two-stage high-current, power-cleaning network consisting of both choke and double Pi filter design. Each of the four remaining medium-current outlets (for source components) feature four independent six-stage delta filter power-cleaning networks. These give almost 20dB of power cleaning at 1kHz (reference 600 ohms); this then improves to almost 40dB at 10kHz, ten times greater than the recommended standard. A further five independent filter stages are placed between each output. Featuring IsoTek’s Adaptive Gating system, this design is engineered to eliminate Differential Mode cross-contamination between each power outlet.

Indeed, the V5 Elektra dramatically reduces both Differential Mode and Common Mode noise. Cross-contamination of connected components is also kept to a minimum due to the multiple power-cleaning stages—one for each output socket.

The printed circuit board (PCB) design and topology has twice the industry standard copper loading and is silver plated to improve amperage and decreased resistance. Significantly improved Direct Current Resistance (DCR) has been applied throughout this new design. Part of the overall IsoTek goal is to reduce DCR in order to bring performance closer to the zero ohms ideal. Numerous technological improvements have resulted in the V5 Elektra delivering 10A of absolute power, and unrestricted current delivery (close to 16A transient) within the power company standard.

KERP (Kirchhoff’s Equal Resistance Path) ensures equal resistance and equal power delivery to all outlets. The internal wiring is of the highest standard, with a unique design featuring pure 6n oxygen free copper conductor strands, each silver-plated, offering low resistance and high amperage. An aerospace-grade Fluorinated Ethylene Propylene (FEP) dielectric, with very low dielectric resistance, is used to protect the conductors as well as giving an ideal conductor contact dielectric for the internal power delivery system.

The V5 Elektra also contains a System Link outlet, designed to connect multiple units together, while maintaining a star earth reference. And, like all Music Direct products, the V5 Elektra comes with the 100% Music Direct Satisfaction Guarantee.

Innovative V5 Products
When IsoTek launched Version Five (or V5 for short), it was much more than merely a series update. Each aspect of every product has been fundamentally improved, from industrial design to PCB topology, with unique components being substantially upgraded in terms of size, inductance, and current-handling capabilities. Tolerances have been improved. Increased copper loading and circuit configurations are engineered to bring the overall Direct Current Resistance closer to the zero ohms ideal. The levels of protection against power surges and voltage spikes have been substantially improved as well.

About IsoTek
IsoTek was born with a singular aim: to create a better solution to the problem of poor mains quality, which restricts the performance of audio systems. The company was founded by Keith Martin, whose vision has led to dozens of awards from respected critics and audiophile publications. From the very beginning to today, IsoTek has remained committed to achieving its goals through rigorous research, scientific testing, and genuine innovation. IsoTek products supply clean, fully optimized power to all manner of audio and AV equipment—from amps and source components to TVs and projectors—thus enhancing performance and protecting valuable equipment around the globe.
